TL081CD – SMD

درباره این محصول

• Product Category: Operational Amplifiers - Op Amps
• Manufacturer: Texas Instruments
• RoHS: RoHS Compliant Details
• Mounting Style: Through Hole
• Package/Case: SOIC-8
• Supply Voltage - Max: 36 V
• Number of Channels: 1 Channel
• GBP - Gain Bandwidth Product: 3 MHz
• SR - Slew Rate: 13 V/us
• CMRR - Common Mode Rejection Ratio: 70 dB
• Ib - Input Bias Current: 400 pA
• Vos - Input Offset Voltage: 15 mV
• Supply Voltage - Min: 7 V
• Operating Supply Current: 2.8 mA
• Maximum Operating Temperature: + 70 C
• Minimum Operating Temperature: 0 C
• Shutdown: No Shutdown
• Series: TL081
• Packaging: Tube
• Amplifier Type: General Purpose Amplifier
• Brand: Texas Instruments
• Dual Supply Voltage: +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
• en - Input Voltage Noise Density: 18 nV/sqrt Hz
• Height: 4.57 mm
• In - Input Noise Current Density: 0.01 pA/sqrt Hz
• Length: 9.81 mm
• Maximum Dual Supply Voltage: +/- 18 V
• Minimum Dual Supply Voltage: +/- 3.5 V
• Operating Supply Voltage: 7 V to 36 V, +/- 3.5 V to +/- 18 V
• Pd - Power Dissipation: 670 mW
• Product: Operational Amplifiers
• PSRR - Power Supply Rejection Ratio: 70 dB
• Factory Pack Quantity: 2500
• Supply Type: Single, Dual
• Technology: BiFET
• Vcm - Common Mode Voltage: Negative Rail + 4 V to Positive Rail - 4 V
• Voltage Gain dB: 106.02 dB
• Width: 6.35 mm
• Unit Weight: 440,400 m
• آی سی TL081 یک آپ امپ ( تقویت کننده عملیاتی ) تکی با ورودی JFET و با نویز کم و پهنای باند 3 مگاهرتز می باشد.
