LM2902 – SMD

درباره این محصول

• oduct Category: Operational Amplifiers - Op Amps
• Manufacturer: ST Semiconductor
• RoHS: RoHS Compliant Details
• Mounting Style: Through Hole
• Package/Case: SO-14
• Supply Voltage - Max: 26 V
• Output Current per Channel: 40 mA
• Number of Channels: 4 Channel
• CMRR - Common Mode Rejection Ratio: 50 dB
• Ib - Input Bias Current: 250 nA
• Vos - Input Offset Voltage: 7 mV
• Supply Voltage - Min: 3 V
• Operating Supply Current: 1.2 mA
• Maximum Operating Temperature: + 85 C
• Minimum Operating Temperature: - 40 C
• Shutdown: No Shutdown
• Series: LM2902
• Packaging: Bulk
• Amplifier Type: High Gain Amplifier
• Brand: Fairchild Semiconductor
• Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V
• Height: 3.56 mm (Max)
• Length: 19.56 mm (Max)
• Maximum Dual Supply Voltage: +/- 13 V
• Minimum Dual Supply Voltage: +/- 1.5 V
• Operating Supply Voltage: 3 V to 26 V, +/- 1.5 V to +/- 13 V
• Pd - Power Dissipation: 1310 mW
• Product: Operational Amplifiers
• PSRR - Power Supply Rejection Ratio: 50 dB
• Factory Pack Quantity: 2500
• Supply Type: Single, Dual
• Technology: Bipolar
• Voltage Gain dB: 100 dB
• Width: 6.6 mm (Max)
• Unit Weight: 0.620 g
• آی سی LM2902N یک اپ امپ شامل چهار تقویت کننده مستقل با گین بالا می باشد.
