HEF4081BT – SMD

درباره این محصول

• Product Category: Logic Gates
• Manufacturer: Texas Instruments
• RoHS: RoHS Compliant Details
• Product: Single-Function Gate
• Logic Function: AND
• Logic Family: CD4000
• Number of Gates: 4 Gate
• Number of Input Lines: 2 Input
• Number of Output Lines: 1 Output
• High Level Output Current: - 1.5 mA
• Low Level Output Current: 1.5 mA
• Propagation Delay Time: 12 ns
• Supply Voltage - Max: 18 V
• Supply Voltage - Min: 3 V
• Maximum Operating Temperature: + 125 C
• Mounting Style: SMD/SMT
• Package/Case: SOIC-14
• Packaging: Reel
• Brand: Texas Instruments
• Function: AND
• Height: 1.58 mm
• Input Type: CMOS
• Length: 8.65 mm
• Logic Type: 2-INPUT AND
• Minimum Operating Temperature: - 55 C
• Number of Bits: 4 bit
• Operating Supply Current: 15 uA
• Operating Supply Voltage: 10 V
• Operating Temperature Range: - 55 C to + 125 C
• Output Type: CMOS
• Quiescent Current: 20 nA
• Series: CD4081B , HEF4081BT , HCF4081B , TC4081B
• Factory Pack Quantity: 2500
• Width: 3.91 mm
• Unit Weight: 0.5 mg
• آی سی CD4081B  شامل 4 عدد گیت NAND با دو ورودی می باشد.
