CD4538BE – DIP

درباره این محصول

• Product Category: Monostable Multi-vibrator
• Manufacturer: Fairchild Semiconductor
• RoHS: RoHS Compliant Details
• Elements per Chip: 2
• Logic Family: CD4000
• Logic Type: Monostable Multivibrator
• Package/Case: PDIP-16
• Supply Current - Max: 0.02 mA
• Propagation Delay Time: 600 ns, 300 ns, 220 ns
• High Level Output Current: - 4.2 mA
• Low Level Output Current: 4.2 mA
• Supply Voltage - Max: 15 V
• Supply Voltage - Min: 3 V
• Maximum Operating Temperature: + 125 C
• Minimum Operating Temperature: - 55 C
• Packaging: Tube
• Brand: Fairchild Semiconductor
• Height: 3.3 mm
• Length: 19.81 mm
• Mounting Style: Through Hole
• Operating Supply Voltage: 3.3 V, 5 V, 9 V, 12 V
• Factory Pack Quantity: 25
• Width: 6.35 mm
• Unit Weight: 2 g
• CD14538B , HEF4538B , HCF4538B
• آی سی CD4538B شامل دو مولتی ویبراتور می باشد.
